Product Details:
|
| Place Of Origin: | Guangzhou, China (Mainland) | Name: | Ro Membrane Housing |
|---|---|---|---|
| Material: | Wooden Box, FRP | Weight: | As Demand |
| Size: | Customized, As Demand | After-sales Service Provided: | Video Technical Support, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Free Spare Parts, Online Support |
| Warranty: | 1 Year | Product Name: | Ro Membrane Vessel |
| Application: | Water Purification | Certification: | ISO |
| Package: | Wooden Crate | Type: | Water Filter Parts |
| Color: | Customerized | ||
| Highlight: | reverse osmosis membrane housing,8040 membrane housing |
||
FRP membrane housing
Pressure membrane housing ro membrane housing frp membrane housing
FRP membrane housing, membrane housing
4" FRP membrane housing
Product Selection
4040End Port, Side Port
Pressure:300,450,600,800,1000PSI；
Length:1-5core (element)；
The appearance of colors:White for the standard configuration can be based on customer can be customized.
Technical Requirements Membrane housing manufacturing methods in accordance with standard JC692-1998；
The membrane housing designed to pressure 300,450,600,800,1000PSI；
Allowed operating temperature range:-7℃~49℃；
The pressure infiltration test experiment of membrane housing is using the experimental
pressure of 1.5 times the standard pressure.
8" FRP membrane housing
Product Selection
8040Side Port(Including cellular panels),End Port；
Pressure:300,450,600,800,1000PSI；
Length:1-7core (element)；
The appearance of colors:White for the standard configuration can be based on customer can be customized.
Technical Requirements
Pressure:300,450,600,800,1000PSI；
Allowed operating temperature range: -7℃~49℃；
Intake standard thread connection 1-1, 2 inch hold joint hoop；
Guangzhou, Jieming Water Treatment Equipment Co., Ltd. special offer FRP membrane housing professional manufacturer. We have the excellent quality, perfect after-sales service and competitive price, and we have won the trust of customers.
FRP membrane housing model selection table:
| Spec. | Type | Type | Type | Type | Type |
| 300PSI | 450PSI | 600PSI | 800PSI | 1000PSI | |
| 8 inch for 1 module |
R8040C30E-1 R8040C30S-1 |
R8040C45E-1 R8040C45S-1 |
R8040C60E-1 R8040C60S-1 |
R8040C80E-1 R8040C80S-1 |
R8040C100E-1 R8040C100S-1 |
| 8 inch for 2 modules |
R8040C30E-2 R8040C30S-2 |
R8040C45E-2 R8040C45S-2 |
R8040C60E-2 R8040C60S-2 |
R8040C80E-2 R8040C80S-2 |
R8040C100E-2 R8040C100S-2 |
| 8 inch for 3 modules |
R8040C30E-3 R8040C30S-3 |
R8040C45E-3 R8040C45S-3 |
R8040C60E-3 R8040C60S-3 |
R8040C80E-3 R8040C80S-3 |
R8040C100E-3 R8040C100S-3 |
| 8 inch for 4 modules |
R8040C30E-4 R8040C30S-4 |
R8040C45E-4 R8040C45S-4 |
R8040C60E-4 R8040C60S-4 |
R8040C80E-4 R8040C80S-4 |
R8040C100E-4 R8040C100S-4 |
| 8 inch for 5 modules |
R8040C30E-5 R8040C30S-5 |
R8040C45E-5 R8040C45S-5 |
R8040C60E-5 R8040C60S-5 |
R8040C80E-5 R8040C80S-5 |
R8040C100E-5 R8040C100S-5 |
| 8 inch for 6 modules |
R8040C30E-6 R8040C30S-6 |
R8040C45E-6 R8040C45S-6 |
R8040C60E-6 R8040C60S-6 |
R8040C80E-6 R8040C80S-6 |
R8040C100E-6 R8040C100S-6 |
| 8 inch for 7 modules |
R8040C30E-7 R8040C30S-7 |
R8040C45E-7 R8040C45S-7 |
R8040C60E-7 R8040C60S-7 |
R8040C80E-7 R8040C80S-7 |
R8040C100E-7 R8040C100S-7 |
| 4 inch for 1 module |
R4040C30E-1 R4040C30S-1 |
R4040C45E-1 R4040C45S-1 |
/ | / |
R4040C100E-1 R4040C100S-1 |
| 4 inch for 2 modules |
R4040C30E-2 R4040C30S-2 |
R4040C45E-2 R4040C45S-2 |
/ | / |
R4040C100E-2 R4040C100S-2 |
| 4 inch for 3 modules |
R4040C30E-3 R4040C30S-3 |
R4040C45E-3 R4040C45S-3 |
/ | / |
R4040C100E-3 R4040C100S-3 |
| 4 inch for 4 modules |
R4040C30E-4 R4040C30S-4 |
R4040C45E-4 R4040C45S-4 |
/ | / |
R4040C100E-4 R4040C100S-4 |
Application for FRP MEMBRANE HOUSING:
Package for FRP MEMBRANE HOUSING:
Standard export carton packing.
7-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
Company Information
Guangzhou Jieming Water Treatment Equipment Co.,Ltd. is a one-stop purchasing, exporting, delivering service provider in Water industry field, located in ,Xintang town, Zengcheng, Guangzhou,China.
Facilitated with the largest manufacturer of FRP Tank---Dongguan Huayu Jieming FRP Vessle Co.,Ltd.(the founder’s co-owned factory), and plentiful manufacturers of water treatment products in China, we provide the most cost- effective products and considerately customized service for our customers like Engineering Company /Water treatment product distributor and Users in water treatment industry all over the world.
